Automated Report Generation with Papermill: Part 2

Posted by Chris Moffitt in articles

article header image

Introduction

This guest post is the second article about using python tools to automate a report generation pipeline. If you have not read the first post you should probably review before continuing with this article.

Before we get started, I would like to re-introduce the author:

Hey there! My name is Duarte O.Carmo and I’m a digital consultant at Jabra. I absolutely love using python for automation, web development, data science and analysis, or pretty much any other subject. Learn more about me by visiting my website, feel free to get in touch :)

Part 2 - Designing a solution

Welcome to part 2 of this two-part series post about automating report generation using python, jupyter, papermill, and a couple of other tools.

In the first part, we covered 4 main important processes that are part of the automation process. In this second and final part, we will bring everything together and build our report automation system.

Note: This code was written in python 3.7. You might have to adapt the code for older versions of python.

All of the code for this article is available on GitHub.

A workflow to automatically generate reports in a shared cloud folder

Let’s imagine you want to generate automatic reports for every similar excel file of sales reports. You also want to share them with your colleagues. Your colleagues are interested in the reports, but not in learning how to program python, how would you proceed?

There are a lot of options, and hardly any incorrect ones, but one I found particularly interesting was using what a lot of people and companies already use: a cloud folder (Google Drive, OneDrive, Dropbox).

Cloud folders (particularly shared ones) are very popular in companies. So a good idea would be to create a shared folder where everyone can upload sales excel reports, and automatically generate Html reports from them, so everyone can read!

Here is the basic architecture of the solution:

Process Flow

Let’s describe each one of the steps:

  • A user uploads a new excel sales report to a shared cloud folder.
  • We sync the cloud folder with a local folder and detect a new excel sales report.
  • We use papermill to generate a new notebook file from that new excel sales report.
  • We use nbconvert to generate an Html file from that new notebook file.
  • We upload the Html file to the cloud folder, so the user can read it.

Let’s start building this step by step:

1. Sync a cloud folder with a local folder and detect new files

To sync cloud directories with local directories, we will a tool called Rclone. Of course, we will integrate it with python.

Start by installing rclone in the same machine as your local folder (your personal computer or a virtual private server for example).

To do so, on a Mac or Linux machine, you should:

$ curl https://rclone.org/install.sh | sudo bash

On Windows, download the executable in the Rclone downloads page.

Once rclone is installed, we must configure it. Depending on your cloud provider (Dropbox, Google Drive, OneDrive), the instructions will vary, so make sure to follow the configuration instructions.

Once configured, let us do a first sync from the command line:

$ rclone sync remote:REMOTE_FOLDER_NAME LOCAL_FOLDER_NAME

This will sync your local folder with your remote folder.

We can also spark this command from a python script using the core subprocess library. That allows you to run command-line programs from python:

import subprocess

# define our variables
REMOTE_FOLDER_NAME="shared folder"
LOCAL_FOLDER="local folder"

# run the rclone sync command from python
subprocess.run(
        ["rclone", "sync", f"remote:{REMOTE_FOLDER_NAME}", LOCAL_FOLDER]
    )

Now that we know how to sync a local and a cloud directory, how do we detect if a user has uploaded a new file to our cloud directory? Well, an option would be to navigate to our local directory and use the ls command and see what pops out.

Rclone also allows us to list files in our cloud directory. Having this, we can create a python function that detects new files if they have been uploaded to the cloud folder:

def get_new_files(remote_folder, local_folder):
    """
    A function that returns files that were uploaded to the cloud folder and
    do not exist in our local folder.
    """
    # list the files in our cloud folder
    list_cloud = subprocess.run(
        ["rclone", "lsf", f"remote:{remote_folder}"],
        capture_output=True,
        text=True,
    )

    # transform the command output into a list
    cloud_directories = list_cloud.split("\n")[0:-1]

    print(f"In the cloud we have: \n{cloud_directories}")

    # list the files in our local folder
    list_cloud = subprocess.run(
        ["ls", local_folder], capture_output=True, text=True
    )

    # transform the command output into a list
    local_directories = list_cloud.stdout.split("\n")[0:-1]

    print(f"In the local copy we have: \n{local_directories}")

    # create a list with the differences between the two lists above
    new_files = list(set(cloud_directories) - set(local_directories))

    return new_files

A couple of notes about the script above:

  • The capture_output file in the subprocess.run function, allows us to capture the output of the command.
  • The text flag allows us to treat everything as text, avoiding problems with spaces for example.
  • After running subprocess.run , we apply the .split function to parse the output of the subprocess.run function which is a string of different files separated by a line break (\n). This split function allows us to but all the elements into a nicely formatted python list.
  • The new_files list will contain only files that are in the cloud directory, but not in the local directory, or in other words: the excel file that users have uploaded to the cloud drive. In case there are no differences, the function will return an empty list.

2. Using Papermill and Nbconvert to generate new reports

Once we have a reliable way of detecting if new files are uploaded to the cloud, we now need to process that new file and generate an html report from it.

We will use two of the tools mentioned in the first article: papermill, and nbconvert.

We start by creating a function that will produce a new notebook file, based on an excel report. Using, of course, a notebook template (for example template.ipynb ) as previously described in part 1.

import papermill as pm

def run_notebook(excel_report, notebook_template):
    # take only the name of the file, and ignore the .xlsx ending
    no_extension_name = excel_report.split(".")[0]
    # run with papermill
    pm.execute_notebook(
        notebook_template,
        f"{no_extension_name}.ipynb",
        parameters=dict(filename=excel_report),
    )
    return no_extension_name

Then, we must convert the notebook to an Html file. To do this, we create another function that calls the nbconvert command from the python interpreter.

import subprocess

def generate_html_report(notebook_file):
    generate = subprocess.run(
        [
            "jupyter",
            "nbconvert",
            notebook_file,
            "--to=html",
        ]
    )
    print("HTML Report was generated")
    return True

This function runs the nbconvert command previously described in the beginning of the article, from a python script.

4. Uploading an Html file back to the cloud folder

There is another Rclone command that is pretty handy. If you want to push a file from a local folder to a cloud folder, you can use the following from the command line:

$ rclone copy FILENAME remote:REMOTE_FOLDER_NAME

We could do it from the command line, but why not do it from python? With the subprocess library, it’s pretty straightforward:

import subprocess

def push_to_cloud(remote_folder, html_report):
    push = subprocess.run(
        ["rclone", "copy", html_report, f"remote:{remote_folder}"]
    )
    print("Report Published!!!")

5. Bringing it all together

Finally, after giving you a rundown of all of the major tools and processes, here is the full script that scans the cloud folder for new excel sales reports, then generates and uploads an Html analysis of the reports.

The script, cloud_reporter.py follows:

import subprocess
import sys
import papermill as papermill


REMOTE_FOLDER = "your cloud folder name"
LOCAL_FOLDER = "your local folder name"
TEMPLATE_NOTEBOOK = "template_notebook.ipynb"


def get_new_files(remote_folder, local_folder):
    """
    A function that returns files that were uploaded to the cloud folder and do not exist in our local folder.
    """
    # list the files in our cloud folder
    list_cloud = subprocess.run(
        ["rclone", "lsf", f"remote:{remote_folder}"],
        capture_output=True,
        text=True,
    )

    # transform the command output into a list
    cloud_directories = list_cloud.split("\n")[0:-1]

    print(f"In the cloud we have: \n{cloud_directories}")

    # list the files in our local folder
    list_cloud = subprocess.run(
        ["ls", local_folder], capture_output=True, text=True
    )

    # transform the command output into a list
    local_directories = list_cloud.stdout.split("\n")[0:-1]

    print(f"In the local copy we have: \n{local_directories}")

    # create a list with the differences between the two lists above
    new_files = list(set(cloud_directories) - set(local_directories))

    return new_files


def sync_directories(remote_folder, local_folder):
    """
    A function that syncs a remote folder with a local folder
    with rclone.
    """
    sync = subprocess.run(
        ["rclone", "sync", f"remote:{remote_folder}", local_folder]
    )

    print("Syncing local directory with cloud....")
    return sync.returncode


def run_notebook(excel_report, template_notebook):
    """
    A function that runs a notebook against an excel report
    via papermill.
    """
    no_extension_name = excel_report.split(".")[0]
    papermill.execute_notebook(
        template_notebook,
        f"{no_extension_name}.ipynb",
        parameters=dict(filename=excel_report),
    )
    return no_extension_name


def generate_html_report(notebook_file):
    """
    A function that converts a notebook into an html
    file.
    """
    generate = subprocess.run(
        ["jupyter", "nbconvert", notebook_file, "--to=html"]
    )
    print("HTML Report was generated")
    return True


def push_to_cloud(remote_folder, filename):
    """
    A function that pushes to a remote cloud folder
    a specific file.
    """

    push = subprocess.run(
        ["rclone", "copy", filename, f"remote:{remote_folder}"]
    )
    print("Report Published!!!")

def main():
    print("Starting updater..")

    # detect if there are new files in the remote folder
    new_files = get_new_files(
        remote_folder=REMOTE_FOLDER, local_folder=LOCAL_FOLDER
    )

    # if there are none, exit
    if not new_files:
        print("Everything is synced. No new files.")
        sys.exit()
    # else, continue
    else:
        print("There are files missing.")
        print(new_files)

    # sync directories to get new excel report
    sync_directories(remote_folder=REMOTE_FOLDER, local_folder=LOCAL_FOLDER)

    # generate new notebook and extract the name
    clean_name = run_notebook(new_files[0])

    # the new notebook generate will have the following name
    notebook_name = f"{clean_name}.ipynb"

    # generate the html report from the notebook
    generate_html_report(notebook_name)

    # the notebook name will be the following
    html_report_name = f"{clean_name}.html"

    # push the new notebook to the cloud
    push_to_cloud(html_report=html_report_name, remote_folder=ONEDRIVE_FOLDER)

    # make sure everything is synced again
    sync_directories(remote_folder=REMOTE_FOLDER, local_folder=LOCAL_FOLDER)

    print("Updater finished.")

    return True


if __name__ == "main":
    main()

6. Running the updater regularly

Once you get the script running, one option is to copy it to a virtual private server (you can get one in digitalocean.com for example) and have it run regularly via something like cron .

Security Warning
If you are going to sync sensitive company information to a virtual private server, please make sure that you have permission, and that you take necessary security measures to protect the server.

You should read more about cron before messing with it. It allows you to run scripts every X amount of time. A simple approach to our problem would be:

  1. Make sure the script is running successfully in your server by:

    • Installing and configuring rclone.
    • Installing jupyter and nbconvert.
    • Creating a local folder to serve as a remote copy.
    • Modifying the script above with your variables (base notebook, remote folder name, and local folder name).
    • Making sure the script runs.
  2. Editing your crontab by:

    $ crontab -e

  3. Adding a crontab job that navigates to a certain directory and runs the cloud_reporter.py file, every X minutes using python.

    Here is an example of it running every 4 minutes:

    */4 * * * * python /path/to/your/folder/cloud_reporter.py

  4. Uploading a new excel file to your cloud folder and wait a minimum of 4 minutes, and a new Html report should be generated and uploaded automatically!

  5. Give access to the shared cloud folder (Dropbox, Google Drive) to your colleagues, and let them upload any excel report.

Final thoughts

And just like this, we reach the end of this article series!

Hopefully, these tools and scripts will inspire you to go out and automate report generation or any other process around you. Making it as simple as possible to your colleagues to generate reports.

I would like to thank Chris for allowing me to collaborate with him in these posts. I really had a blast building these tools and writing these “guides”. A team effort that started with a simple reach out on twitter:

Twitter reach out

All of the code for this article series is in this GitHub repo.
